AM ACE CRYSTAL 40
AM ACE CRYSTAL 50
Full-featured, powerful AM (Acousto- Magnetic) ACE system is focused on strong detection of adhesive labels, reliability, and flexibility. It was designed to operate as one or several pedestals solution.
Our ACE CRYSTAL system is suitable for any environment, with a performance that ranks at the top of the retail security market. The premium acrylic panel of the CRYSTAL design allows it to blend seamlessly to modern or premium retail spaces - the ideal fusion of function and design.
The ACE CRYSTAL supports remote connectivity and data collection and can also be connected to our STOREMONITOR cloud platform for advanced system analytics and store performance reports.
In addition to all these options and features, the system is equipped with our new smart ECO MODE that saves up to 35% of the EAS energy consumption. This way we help to reduce our customer’s unnecessary utility costs, increase lifespan of the system and stay environmentally friendly.
Remote connectivity and data collection are standard inbuilt features of our systems. It ensures that our systems are not only
easy to install but can also be serviced and maintained remotely with fast response and without unnecessary travel costs.
The premium crystal acrylic panel of CRYSTAL design is manufactured from the highest grade, preventing discoloration
and warping. The included multi-colored LED lights can be configured to not only display the alarm colour that you wish,
but also to light the antenna permanently in an attractive glow.
Retailers facing losses due to professional shoplifters equipped with foil-lined bags, can upgrade their AM ACE systems with the license-based metal detection that is easily available for extra security.
When connected to our STOREMONITOR cloud analytics all essential data from visitor counters, alarm management
and system operation are available for further processing. You can evaluate your store or system performance in advanced
graphs and overviews or set up reports to be automatically sent to your mailbox or uploaded to your existing system.
- Remote maintenance and diagnostics
- MetalMagnet detection
- Visitor counting
- Additional alarm outputs
- Smart directional alarms
- Jammer detector
- Tag too close indication
- Decoration light
- ECO MODE enabled systems
| PEDESTAL COMPARISON | CRYSTAL 40 | CRYSTAL 50 |
|---|---|---|
| FEATURES / OPTIONS | ||
| ADVERTISEMENT PANELL | ||
| INTEGRATED METAL DETECTION | ||
| INTEGRATED VISITOR COUNTING | ||
| SMART DIRECTIONAL ALARMS | ||
| REMOTE MAINTENANCE AND DIAGNOSTICS | ||
| POWER SAVING MODE | ||
| COLOUR OPTIONS | S /B / W | S /B / W |
| DIMENSIONS | ||
| HEIGHT | 151 cm | 151 cm |
| WIDTH | 39.5 cm | 49.5 cm |
| DEPTH | 2.0 cm | 2.0 cm |
| ADVERTISEMENT PANEL (H × W) | ||
| WEIGHT | 16.1 kg | 19.6 kg |
| BASE DIMENSIONS | 23.3 × 35.5 × 10.3 cm | 23.3 × 42.4 × 10.3 cm |
| DETECTION RANGE | ||
| DETECTION RANGE SOFT LABELS | MONO / DUAL | MONO / DUAL |
| up to 115 / 230 cm | up to 125 / 250 cm | |
| DETECTION RANGE HARD TAG | MONO / DUAL | MONO / DUAL |
| up to 155 / 310 cm | up to 165 / 330 cm | |
| PRODUCT CODES | ||
| SILVER COLOUR | AS-AC4S-PPC | AS-AC5S-PPC |
Legend: included not available optional
1tested with original DR labels in all orientations. 2tested with original AMERSEC® pencil tags in all orientations. 3minimum of 2 pedestals required.
Accessories
AM ACE Power Box Duo
Can power up to 2 pedestals
DIMENSIONS (H×W×D) 4.5 × 13.5 × 17 cm
WEIGHT 0.9 kg
CODE AS-APSXD
AM ACE Power Box Single
Can power one pedestalDIMENSIONS (H×W×D) 4.0 × 6.0 × 12.0 cm
WEIGHT 0.3 kg
CODE AS-APSXS
